Field Service Ver. 1.0 Aug. 2005 8. Trouble code
29
PC-402
Troubleshooting
8. Trouble code
8.1 Trouble code display
• The main unit's CPU performs a self-diagnostics function that, on detecting a malfunc-
tion, gives the corresponding malfunction code on the Touch Panel.
8.2 Trouble code list
4040F4E510DA
Code Item Description
C0001 LCT communication error
• Due to a software malfunction, etc., the time on the
watchdog timer has run out and a reset is performed.
C0209 LCT Elevator Motor Failure
• The Elevator Motor Pulse Sensor (PC10-LCT) cannot
detect both edges of H/L even after the set period of
time has elapsed while the Elevator Motor (M5-LCT) is
turning backward/forward (raise/lower).
To Next Page
