Develop ineo 350 - C11 A0: Paper Holding Drive Failure; C11 A1: Exit Roller Pressure;Retraction Failure

10. Malfunction code Field Service Ver. 1.0 Aug. 2005
44
FS-508/PU-501/OT-601
Troubleshooting
10.2.4 C11A0: Paper Holding Drive Failure
10.2.5 C11A1: Exit Roller Pressure/Retraction Failure
Relevant Electrical Parts
Exit Paddle Solenoid (SL2-FN)
Exit Paddle Home Position Sensor (PC11-FN)
Main Control Board (PWB-A FN)
Step Action
WIRING DIAGRAM
Control Signal
Location
(Electrical Component)
1
Check the SL2-FN connector for
proper connection and correct as
necessary.
--
2 PC11-FN I/O check PWB-A FN PJ17A FN-7 (ON) FS-508 B-7
3 SL2-FN operation check PWB-A FN PJ18A FN-6 (REM) FS-508 B-7
4 Change PWB-A FN - -
Relevant Electrical Parts
Exit Open/Close Motor (M6-FN)
Exit Roller Home Position Sensor (PC12-FN)
Main Control Board (PWB-A FN)
Step Action
WIRING DIAGRAM
Control Signal
Location
(Electrical Component)
1
Check the M6-FN connector for
proper connection and correct as
necessary.
--
2
Check M6-FN for proper drive cou-
pling and correct as necessary.
--
3 M6-FN operation check PWB-A FN PJ20A FN-1 to 2 FS-508 B-6
4 PC12-FN I/O check PWB-A FN PJ20A FN-7 (ON) FS-508 B-5
5 Change PWB-A FN - -
