Develop ineo 350 - C0215: LCT Shift Motor Failure

Field Service Ver. 1.0 Aug. 2005 8. Trouble code
35
PC-402
Troubleshooting
8.3.7 C0215: LCT Shift Motor Failure
Relevant electrical parts
Shift Motor (M4-LCT)
Shift Motor Pulse Sensor (PC8-LCT)
Main Control Board (PWB-C1 LCT)
Step Action
WIRING DIAGRAM
Control signal
Location
(Electrical com-
ponents)
1
Check the motor and sensor connectors
for proper connection, and correct as
necessary.
--
2
Check the connector of motor for proper
drive coupling, and correct as neces-
sary.
--
3 PC8-LCT sensor check PWB-C1 LCT PJ2H<A> LCT-3 (ON) PC-402 G-5
4 M4-LCT operation check PWB-C1 LCT PJ2H<B> LCT-4 to 5 PC-402 G-6
5 PWB-C1 LCT replacement - -
