8. Trouble code Field Service Ver. 1.0 Aug. 2005
26
PC-102/PC-202
Troubleshooting
8. Trouble code
8.1 Trouble code display
• The main unit’s CPU performs a self-diagnostics function that, on detecting a malfunc-
tion, gives the corresponding malfunction code on the Touch Panel.
8.2 Trouble code list
• Open and close the Front Door or turn OFF and ON the Main Power Switch.
4040F4E510DA
Code Item Description
C0206 Tray3 Lift-Up Failure • The Lift-Up Sensor is not blocked even after the set
period of time has elapsed after the paper lift-up
operation for the drawer began.
C0208 Tray4 Lift-Up Failure
To Next Page
