Develop ineo 350 - Duplex Unit

Field Service Ver. 1.0 Aug. 2005 23. Parts layout drawing
277
bizhub 200/250/350Appendix
23.2 Duplex Unit
[1] Duplex Unit Door Sensor (PC23) [4] Duplex Unit Transport Clutch 2 (CL7)
[2] Duplex Unit Upper Transport Sensor (PC24) [5] Duplex Unit Transport Clutch 1 (CL6)
[3] Duplex Unit Lower Transport Sensor (PC25)
4040F5C502DA
[1]
[2]
[3]
[4]
[5]
