Field Service Ver. 1.0 Aug. 2005 18. Jam Display
225
bizhub 200/250/350
Troubleshooting
18.3.2 Misfeed at Tray 1 take-up section
A. Detection Timing
B. Action
Type Description
Detection of misfeed at
Tray 1 take-up section
The leading edge of the paper does not block the Synchronizing Roller
Sensor (PC1) even after the set period of time has elapsed after the 1st
Drawer Paper Feed Clutch (CL3) has been energized.
Size error detection
The Synchronizing Roller Sensor (PC1) is not unblocked even after the set
period of time has elapsed after the sensor has been blocked by the paper.
The Synchronizing Roller Sensor (PC1) is unblocked before the set period
of time.
Relevant Electrical Parts
Synchronizing Roller Sensor (PC1)
1st Drawer Paper Feed Clutch (CL3)
Mechanical Control Board (PWB-A)
Step Action
WIRING DIAGRAM
Control Signal
Location
(Electrical
Component)
1 Initial check items - -
2 PC1 I/O check PWB-A PJ11A-5 (ON) M-8
3 CL3 operation check PWB-A PJ22A-14 (ON) D-7
4 Change PWB-A - -
To Next Page
