Field Service Ver. 1.0 Aug. 2005 18. Jam Display
231
bizhub 200/250/350
Troubleshooting
18.3.8 Misfeed at Manual Bypass take-up section
A. Detection Timing
B. Action
Type Description
Detection of misfeed at
Manual Bypass take-up
section
The leading edge of the paper does not block the Vertical Conveyance Sen-
sor (PC2) even after the set period of time has elapsed after the Bypass
Paper Feed Clutch (CL5) has been energized.
Detection of paper left in
Manual Bypass take-up
section
The Vertical Conveyance Sensor (PC2) is blocked when the Main Power
Switch is set to ON, a door or cover is opened and closed, or a misfeed or
malfunction is reset.
Relevant Electrical Parts
Vertical Conveyance Sensor (PC2)
Bypass Paper Feed Clutch (CL5)
Mechanical Control Board (PWB-A)
Step Action
WIRING DIAGRAM
Control Signal
Location
(Electrical
Component)
1 Initial check items - -
2 PC2 I/O check PWB-A PJ22A-9 (ON) D-7
3 CL5 operation check PWB-A PJ13A-14 (ON) M-11
4 Change PWB-A - -
To Next Page
