20. Power supply trouble Field Service Ver. 1.0 Aug. 2005
250
bizhub 200/250/350
Troubleshooting
20.3 The Start key (LED) on the control panel blinks green
Relevant Electrical Parts
Total Counter Control Panel (UN1)
Step Check Item
Location
(Electrical
Component)
Result Action
1 Is the Total Counter connector connected? - NO Connect
2 Is the machine in the Initial mode? - YES
Turn OFF the Main Power
Switch, wait for 10 sec. or
more, and turn ON the
Main Power Switch.
To Next Page
