FK-503Adjustment / Setting
NOTE
• The features with (*) are settable by users. *: Screen setting
MODE Factory setting bit
038
Bit: 7654 3210
0000 1010
HEX:0A
Bit Feature
Logic
Description
01
7 Turn on print lamp when
out-of-paper.
On when
all cas-
settes are
out of
paper
On when
at least
one cas-
sette is out
of paper
3 Print restart timer after
stopping.
Bit 3-2: 00 3 min
2015 min
10 10 min
11 20 min
1 Manual setting of print
stop/start. *
Stop
Start
0 Print stop/start timer. *
Does not
function
Function
MODE Factory setting bit
040
Bit: 7654 3210
1111 1010
HEX:FA
Bit Feature
Logic
Description
01
7 2-dim coding at TX.
(Valid for G3 communication)
No
Yes “No”: MH
“Yes”: MH + MR
6 T.6 coding.
(Valid for G3 communication)
No
Yes “Yes”: MH + MR + MMR
Valid only when “2-dim coding?
(MODE 040 Bit 7)” is set to “Yes.”
5 JBIG communication.
(Valid for ECM communica-
tion)
No
Yes
4 Third party’s JBIG (ITU-T)
communication.
(Valid for ECM communica-
tion)
No
Yes Valid only when “JBIG communica-
tion? (MODE 040 Bit 5)” is set to
“Yes.”
3 Proprietary JBIG (ITU-T)
communication.
(Valid for ECM communica-
tion)
No
Yes Valid only when “JBIG communica-
tion? (MODE 040 Bit 5)” is set to
“Yes.”
1 JBIG capability at V.34 com-
munication. (G3)
No
Yes Valid only when “JBIG communica-
tion? (MODE 040 Bit 5)” is set to
“Yes.”
