Field Service Ver. 1.0 Aug. 2005 11. Soft Switch List
91
FK-503Adjustment / Setting
MODE Factory setting bit
093 (PSTN1)
Bit: 7654 3210
0100 1000
HEX:48 (For U.S.)
HEX:40 (For Europe)
123 (PSTN2)
HEX:48 (For U.S.)
HEX:48 (For Europe)
Bit Feature
Logic
Description
01
7 Select timing for starting
CED sending.
Bit 7-6: 00 0 msec Specifies time interval
from line connection to
starting sending CED.
(7-sec is provided for the
second dial.)
6
01 2000 msec
10 2500 msec
11 7 sec
5 Select CED frequency. Bit 5-4:
00 2100 Hz Specifies frequency to
carry CED or N/A selec-
tion.
4 01 1080 Hz
10 1300 Hz
11 Not available
3 Process CED echo.
No Yes Specifies whether to process CED echo
at the intervals of 500 ms between CED
and initial identification.
2 Process incoming com-
mand echo.
No Yes Specifies whether to process incoming
echo at the intervals of 500 ms between
when receiving an initial identification
and when sending the incoming com-
mand.
1 Control channel data rate. Bit 1-0:
00 1200 bps
0 01 Non 1200 bps
10 2400 bps
11 Non 2400 bps
MODE Factory setting bit
094 (PSTN1)
124 (PSTN2)
Bit: 7654 3210
0000 1100
HEX:0C
Bit Feature
Logic
Description
01
3 Lock AGC in V.33 mode. No
Yes
2 Lock AGC in V.17 mode. No
Yes
1 Lock AGC in V.29 mode.
No Ye s
0 Lock AGC in V.27ter
mode.
No Ye s
