4. Periodical check Field Service Ver. 1.0 Aug. 2005
14
bizhub 200/250/350
Maintenance
E. Periodical parts replacement 5 (per 260,000-print)
F. Periodical parts replacement 6 (per 300,000-print)
G. Periodical parts replacement 7 (per 450,000-print)
No Class Parts to be replaced
Number of
personnel
Check Clean Replace
Lubri-
cation
Descrip-
tions
1
Overall
Paper take-up and
image conditions
●
2 Appearance ●●
3
Processing
section
Developing Unit 1 ●
4 Toner Filter (Main Unit) 1 ●
No Class Parts to be replaced
Number of
personnel
Check Clean Replace
Lubri-
cation
Descrip-
tions
1
Overall
Paper take-up and
image conditions
●
2 Appearance ●●
3
Bypass
Feed Roller 1 ●
4 Separation Roller Assy 1 ●
5
Tray 1
Feed Roller 1 ●
6 Pick-up Roller 1 ●
7 Separation Roller Assy 1 ●
8
Tray 2
Feed Roller 1 ●
9 Pick-up Roller 1 ●
10 Separation Roller Assy 1 ●
11
PC-102
PC-202
PC-402
Pick-up Roller 1 ●
12 Feed Roller 1 ●
13 Separation Roller Assy 1 ●
14 FS-508 Rollers and rolls ●
15 MT-501 Rollers and rolls ●
16 SD-502 Rollers and rolls ●
No Class Parts to be replaced
Number of
personnel
Check Clean Replace
Lubri-
cation
Descrip-
tions
1
Overall
Paper take-up and
image conditions
●
2 Appearance ●●
3
Fusing
section
Fusing Unit 1 ●
