Field Service Ver. 1.0 Aug. 2005 8. Trouble code
31
PC-402
Troubleshooting
• Open and close the Front Door or turn OFF and ON the Main Power Switch.
Code Item Description
C0214 LCT Shift Failure
• The Shifter Return Position Sensor (PC11-LCT) is not
blocked even after the set period of time has elapsed
after the shift operation began (shift to the right).
• The Shifter Return Position Sensor (PC11-LCT) is not
blocked even after the set pulse is detected by the
Shift Motor Pulse Sensor (PC8-LCT) after the shift
operation began (shift to the right).
• The Shifter Home Position Sensor (PC12-LCT) is not
unblocked even after the set pulse is detected by the
Shift Motor Pulse Sensor (PC8-LCT) after the shift
operation began (shift to the right).
• The Shifter Home Position Sensor (PC12-LCT) is not
blocked even after the set period of time has elapsed
after the return operation began (shift to the left).
• The Shifter Home Position Sensor (PC12-LCT) is not
blocked even after the set pulse is detected by the
Shift Motor Pulse Sensor (PC8-LCT) after the return
operation began (shift to the left).
• The Shifter Return Position Sensor (PC11-LCT) is not
unblocked even after the set pulse is detected by the
Shift Motor Pulse Sensor (PC8-LCT) after the return
operation began (shift to the left).
C0215 LCT Shift Motor Failure
• The Shift Motor Pulse Sensor (PC8-LCT) cannot
detect both edges of H/L even after the set period of
time has ward/forward (raise/lower).
