Field Service Ver. 1.0 Aug. 2005 6. I/O Check
25
FS-508/PU-501/OT-601Adjustment / Setting
6.2.2 I/O check list
A. Finisher (FS-508/PU-501)
Symbol Panel display Part/Signal name
Operation characteristics/
Panel display
10
PC5-FN
Finisher
Paper Passage
(Middle)
Transport Sensor
Paper
present
Paper not
present
PC4-FN
Paper Passage
(Feed in)
Entrance Sensor
Paper
present
Paper not
present
PC3-FN
Elevate Tray Upper/
Lowered
Elevator Tray Home Position Sensor
Raised
Position
Not raised
S2-FN Shutter Status Shutter Detection Switch Closed Open
S1-FN Front Door Set Front Cover Detection Switch Closed Open
PC2-PK Punch Pulse Punch Motor Pulse Sensor Blocked Unblocked
PC14-FN Lower (Elev.) Elevator Tray Lower Limit Sensor Blocked Unblocked
PC15-FN Surface (Elev.) Top Face Detection Sensor Blocked Unblocked
-
Optional Tray
(Elevate)
Short Connector Set Not set
PC3-FN Elevate Tray Position Elevator Tray Home Position Sensor Blocked Unblocked
PC6-FN Align Home 1 Alignment Home Position Sensor 1 At home Not at home
PC7-FN Align Home 2 Alignment Home Position Sensor 2 At home Not at home
PC16-FN Home (Shutter) Shutter Home Position Sensor At home Not at home
PC11-FN Paddle Home (Exit) Exit Paddle Home Position Sensor At home Not at home
PC12-FN Exit R Home Exit Roller Home Position Sensor At home Not at home
PC8-FN Empty (Finisher) Storage Tray Detecting Sensor
Paper
present
Paper not
present
PC10-FN Staple Home (CD) Staple Home Position Sensor Blocked Unblocked
- Self Priming Self-Priming Sensor Blocked Unblocked
- Staple Empty Staple Empty Detection Sensor Blocked Unblocked
- Staple Home Staple Home Position Sensor Blocked Unblocked
PC3-PK Punch Pos. 1 Punch Positioning Sensor 1 Unblocked Blocked
PC4-PK Punch Pos. 2 Punch Positioning Sensor 2 Unblocked Blocked
PC1-PK
Punch Scraps Full
Detect
Punch Trash Full Blocked Unblocked
PC22-SK
Home
(Paper Hold R)
Crease Roller Home Position Sensor Blocked Unblocked
S4-FN Middle Guide Transport Jam Detection Switch Closed Open
