Field Service Ver. 1.0 Aug. 2005 5. I/O check
9
MT-501Adjustment / Setting
5.2.2 I/O check list
Symbol Panel display Part/Signal name
Operation characteristics/
Panel display
10
PC10-MK
Finisher
Paper Passage 1
(Mail Bins)
Lower Transport Sensor
Paper
present
Paper not
present
PC9-MK
Paper Passage 2
(Mail Bins)
Upper Transport Sensor
Paper
present
Paper not
present
PC11-MK Mail Bin Door Cover Open/Close Sensor Open Close
PC1-MK 1st Mail Bin Empty Paper Detection Sensor 1
Paper not
present
Paper
present
PC5-MK 1st Mail bin Full Paper Full Detection Sensor 1 Blocked Unblocked
PC2-MK 2nd Mail Bin Empty Paper Detection Sensor 2
Paper not
present
Paper
present
PC6-MK 2nd Mail Bin Full Paper Full Detection Sensor 2 Blocked Unblocked
PC3-MK 3rd Mail Bin Empty Paper Detection Sensor 3
Paper not
present
Paper
present
PC7-MK 3rd Mail Bin Full Paper Full Detection Sensor 3 Blocked Unblocked
PC4-MK 4th Mail Bin Empty Paper Detection Sensor 4
Paper not
present
Paper
present
PC8-MK 4th Mail Bin Full Paper Full Detection Sensor 4 Blocked Unblocked
To Next Page
