Field Service Ver. 1.0 Aug. 2005 6. I/O Check
21
SD-502Adjustment / Setting
6.2.2 I/O check list
A. Finisher (SD-502)
Symbol Panel display Part/Signal name
Operation characteristics/
Panel display
10
PC20-SK
Finisher
Exit (Saddle) Saddle Exit Sensor
Paper
present
Paper not
present
PC21-SK Saddle Empty Saddle Tray Empty Sensor
Paper
present
Paper not
present
S4-SK Saddle Reset Saddle Interlock Switch Open Closed
-
Staple Home 1
(Saddle)
Staple Home Position Sensor 1 Blocked Unblocked
-
Self Priming 1
(Saddle)
Self-Priming Sensor 1 Blocked Unblocked
-
Staple Empty 1
(Saddle)
Staple Empty Detection Sensor 1 Blocked Unblocked
-
Staple Home 2
(Saddle)
Staple Home Position Sensor 2 Blocked Unblocked
-
Self Priming 2
(Saddle)
Self-Priming Sensor 2 Blocked Unblocked
-
Staple Empty 2
(Saddle)
Staple Empty Detection Sensor 2 Blocked Unblocked
PC23-SK
Home (Saddle In &
Out Guide)
In & Out Guide Home Sensor Blocked Unblocked
PC26-SK
Layable Guide
Home (Saddle)
Layable Guide Home Sensor Blocked Unblocked
