6. Selecting and Modifying Fixture Parameters 147
6.1.2 Selecting Multiple Fixtures
You can select more than one fixture using the +, – and Thru keys. For example:
1 +5 , Enter : selects fixtures 1 and 5.
1 Thru 5 , En ter : selects fixtures 1 to 5.
1 Thru 5 – 4 : selects fixtures 1 to 5, but not 4.
1 Thru 5 +7 : selects 1 to 5 and also 7.
5 Thru En ter : selects from fixture 5 of the current type through to the last fixture of
the current type.
Thru Enter : selects all fixtures of the current type.
Note that selections are cumulative, building the total selection, until the selection is used to
perform an action on the selected fixtures. After that, subsequent selections start from
nothing, unless you use + or – to add or subtract from the previous selection.
Tip: To select all fixtures of a particular type, press the Fixture key then Pig + [Fixture
type] from the toolbar at the bottom of the right-hand touch screen.
6.1.3 Selecting fixtures with dotted user numbers
Selecting fixtures with dotted user numbers can be done in a variety of ways. The tables
listed in this section demonstrate all of the supported selection syntax mechanisms
supported by the Hog 4 OS for fixtures with dotted user numbers.
The following examples assume all of the fixtures on the right hand side of the table are
scheduled in the show while the user numbers highlighted in blue are fixtures that have been
selected as a result of the syntax entered on the left hand side of the table:
