80 Hog 4 Operations Manual
5. Check the box if you want the connection to be saved with the console. If this option is
not selected, then this mapping will be lost when the console is rebooted or power
cycled.
6. Check the box to save the password if you wish to have the password for the drive
mapping saved with the above option.
Accessing Network Drives
Once a network drive is mapped, it will appear in the Start and Backup windows under the
console heading as a valid drive to browse to. Sub folders of the primary networked drive will
also be available.
Disconnecting Network Drives
When browsing a network drive, the Eject button is available in the top right corner of the
browse window. Pressing this button will un-map and disconnect the network drive.
3.4 Art-Net and E1.31 (sACN)
Art-Net and E1.31 (also known as streaming ACN) are two communication protocols
supported by the Hog 4 OS that allow for DMX512 data to be sent over Ethernet. While each
protocol is unique in terms of specification and implementation, they both provide the ability
to carry many DMX universes over a single cat 5 Ethernet cable. This section of the manual
will help you to understand how to properly configure your console or Hog 4 PC to output Art-
Net and E1.31.
Platform Art-Net / sACN Output Capability
HPU 64 universes
Hog 4-18 Console 16 universes
Hog 4 Console 16 universes
DMX Processor 8000 16 universes
Full Boar 4 Console 12 universes
Road Hog 4 Console 8 universes
HedgeHog 4X 6 universes
HedgeHog 4 4 universes
Hog 4 PC 12 universes **
** ArtNet and sACN output for a Hog 4 PC universe is enabled by connecting and mapping a
DMX widget and/or an ETCNomad license key to the DMX universe.
