532 Hog 4 Operations Manual
35.9 HedgeHog 4N, 4S, 4X (Jan 2015 and later)
35.9.1 Input and Output Connections
Mains in:
IEC 320 connector (5A/250V rated cable supplied) 100-240V, 50/60Hz, 2.5 A
maximum
Display
Connections:
1 x DVI-D / 1 x VGA (only 1 can be used at a time)
Ethernet: 2 x Gigabit base-TX Ethernet port
USB:
2 x Universal Serial Bus 2.0 ports (2 rear) 2 x Universal Serial Bus3.0 ports (2
rear)
DMX out: 2 x Neutrik 5 pin female XLR
Keyboard: Not included (Generic Class USB keyboards Supported)
35.9.2 Power, Weight and Dimensions
Power: 250W
Weight: 17 lbs (17.5 kg)
Dimensions:
20.74” (526.8mm) wide
21.83” (554.37mm) deep
3.97" (100.78mm) high
