35. Technical Specifications 527
35.4 HPU
35.4.1 Input and Output Connections
Mains in:
V-Lock style locking IEC 320 connector (5A / 250V rated cable supplied) 100-240
VAC, 5A, 50-60 Hz - 1 x 5x20 mm 5A Tfuse
Display
Connections:
2x Display Port Female
Ethernet: 2x Gigabit Ethernet port
USB:
1x front 2.0 port
4 x rear 3.0 ports
2x USB Type-C
DMX out: 8 x Neutrik 5 pin female XLR Galvanized Isolated
35.4.2 Power, Weight and Dimensions
Power: 500w Max
Dimensions:
19" (482.6mm) wide
14" (356.6mm) deep
3.5" (89.1mm) high
35.4.3 HPU Trigger Ports
The trigger ports on the rear of the HPU are removable, field replaceable headers. They are
written below for reference.
ETC Part number: J30215-F
Manufacturer Part number: PHOENIX CONTACT 1844633
