ETC Hog 4 PC - 35.5 Road Hog 4

526 Hog 4 Operations Manual
35.3 Full Boar 4
35.3.1 Input and Output Connections
Mains in:
IEC 320 connector (5A/250V rated cable supplied) 100-240V, 50/60Hz, 5A
maximum
MIDI Connections: MIDI - Input, Output, and Thru Ports
LTC In: 3-pin XLR Linear Timecode Input
Display
Connections:
2 x 24 pin DVI-D single link female connectors
Ethernet: 2 x Neutrik Ethercon; Gigabit Ethernet port
USB: Universal Serial Bus 2.0 ports (4 rear) Universal Serial Bus 3.0 ports (1 top)
DMX out: 4 x Neutrik 5 pin female XLR
Keyboard: Not included (Generic Class USB keyboards Supported)
35.3.2 Power, Weight and Dimensions
Power: 500W
Weight: 45 lbs (20.41 kg)
Dimensions:
35.49” (901 mm) wide
22.65” (575 mm) deep
9.62” (244 mm) high
