35. Technical Specifications 525
35.2 Hog 4-18
35.2.1 Input and Output Connections
Mains in:
V-Lock style locking IEC 320 connector (5A/250V rated cable supplied) 100-240
VAC, 3.2-2A, 50-60 Hz 1 x 5x20mm 5A T fuse
MIDI
Connections:
MIDI - Input, Output, and Thru Ports
LTC In: 3-pin XLR Linear Timecode Input
Display
Connections:
3 x Display Port female connectors
Ethernet: 2 x Neutrik Ethercon; Gigabit Ethernet port
USB: Universal Serial Bus 2.0 ports (6 rear, 2 inside front utility tray)
DMX out: 8 x Neutrik 5 pin female XLR Galvanized Isolated
Keyboard: Built-in Miniature QWERTY keyboard
Mounting: 2 x 5/8" spigot receivers
35.2.2 Power, Weight and Dimensions
Power: 120W Max
Weight: 92 lbs (42 kg)
Dimensions with Screen Down:
39.1” (994mm) wide
29.4” (746mm) deep
6.7” (169mm) high
Dimensions with Screen Up:
39.1” (994mm) wide
29.4” (746mm) deep
16.9” (430mm) high
