534 Hog 4 Operations Manual
35.11 Nano Hog 4
35.11.1 Input and Output Connections
Mains in: External DC Power Supply (5.5A/12V) 100-240V, 50/60Hz, 1.5A maximum
USB: Type B USB Input Socket Universal Serial Bus 2.0 ports (2 rear)
DMX out: 4 x 5-pin XLR DMX Outputs (when DMX output kit is installed)
35.11.2 Power, Weight and Dimensions
Power: 5W
Weight: 18.1 lbs (8.21 kg)
Dimensions:
26.7” (678 mm) wide
13.76” (349 mm) deep
3.54” (89 mm) high
