35. Technical Specifications 531
35.7 HedgeHog 4
35.7.1 Input and Output Connections
Mains in:
IEC 320 connector (5A/250V rated cable supplied) 100-240V, 50/60Hz, 2.5 A
maximum
Ethernet: 1 x Gigabit base-TX Ethernet port
USB: 2 x Universal Serial Bus 2.0 ports (rear)
DMX out: 2 x Neutrik 5 pin female XLR
Keyboard: Not included (Generic Class USB keyboards Supported)
35.7.2 Power, Weight and Dimensions
Power: 250W
Weight: 17 lbs (7.7 kg)
Dimensions:
20.74” (526 mm) wide
21.83” (554 mm) deep
3.97" (100 mm) high
35.8 HedgeHog 4N
35.8.1 Input and Output Connections
Mains in:
IEC 320 connector (5A/250V rated cable supplied) 100-240V, 50/60Hz, 2.5 A
maximum
Ethernet: 2 x Gigabit base-TX Ethernet port
USB: 2 x Universal Serial Bus 2.0 ports (rear)
DMX out: 2 x Neutrik 5 pin female XLR
Keyboard: Not included (Generic Class USB keyboards Supported)
35.8.2 Power, Weight and Dimensions
Power: 250W
Weight: 17 lbs (7.7 kg)
Dimensions:
20.74” (526 mm) wide
21.83” (554 mm) deep
3.97" (100 mm) high
