524 Hog 4 Operations Manual
35.1 Hog 4
35.1.1 Input and Output Connections
Mains in:
V-Lock style locking IEC 320 connector (5A/250V rated cable supplied) 100-240
VAC, 3.2-2A, 50-60 Hz 1 x 5x20mm 5A T fuse
MIDI
Connections:
MIDI - Input, Output, and Thru Ports
LTC In: 3-pin XLR Linear Timecode Input
Display
Connections:
3 x DVI-I single link female connectors
Ethernet: 2 x Neutrik Ethercon; Gigabit Ethernet port
USB: Universal Serial Bus 2.0 ports (6 rear, 1 inside front utility tray, 1 inside armrest)
DMX out: 8 x Neutrik 5 pin female XLR Galvanized Isolated
Keyboard: Built-in Miniature QWERTY keyboard
35.1.2 Power, Weight and Dimensions
Power: 300W
Weight: 75 lbs (34 kg)
Dimensions with Screen Down:
40.5” (1028.7mm) wide
28.49” (723.7mm) deep
6.49” (164.8mm) high
Dimensions with Screen Up:
40.5” (1028.7mm) wide
28.49” (723.7mm) deep
16.43” (417.4mm) high
