35. Technical Specifications 535
35.12 DMX Processor 8000
35.12.1 Input and Output Connections
Mains in: V-Lock style locking IEC 320 connector 100-240V, 50/60Hz, 4A maximum
Ethernet: EtherCon Gigabit Ethernet port (x2)
USB: USB-A 2.0 High Speed (x2)
DMX out: Neutrik 5 pin female XLR Isolated, Half Duplex DMX512 outputs (x8)
35.12.2 Power, Weight and Dimensions
Power: 200W
Weight: 5.9 lbs (2.7 kg)
Dimensions:
19 in (480mm) wide
11 in (280mm) deep
1.77 in (45mm) high
