64 Hog 4 Operations Manual
3.2.10 Checking a DMX Processor's Status
The indicator lights on the front of a DMX Processor 8000 display its status on the network.
Light On Blinking Off
Status Connected to a show Connecting
Not Connected
to a show
DMX Data DMX Data output 2Hz Keep Alive No DMX sending
Net Data Art-Net output
Art-Net configured, but not
connected
Art-Net not
configured
USB
USB Device connected
and active
USB Device found but not
configured
No USB Device
found
HogNet
Link light for HogNet
connection
HogNet activity
HogNet not
connected
FixtureNet
(Art-Net)
Link light for fixture
connection
Fixture activity
Fixture not
connected
Write Writing flash memory
Fast:bootloader
activeSlow:updating firmware
Normal activity
