RX4770 M1 Upgrade and Maintenance Manual 179
Expansion cards and backup units
Ê Secure the TFM on the controller (from controller side) with the three
screws.
Ê Install the expansion card as described in section "Installing expansion
cards" on page 142.
RAID controller D3216
Figure 75: Installing the TFM (A)
Ê If no TFM has been installed before: fit the two spacer bolts on the RAID
controller.
