4.5 Setting Application Settings
122
Range synchronization function settings (basic)
Procedure
LCR Measurement Screen LCR Basic Settings (Range Synchronization Function)
1
When the range synchronization function is enabled (p. 120)
Press .
2
LCR Basic Settings (Range Synchronization Function)
3
Select the measurement range you wish to
configure with and and configure the
associated functions.
LCR Range Synchronization Function
Settings Screen (Basic)
4
Press to close the setting screen.
Settings are the same as those described in "4.2 Setting Ba-
sic Settings of Measurement Conditions" (p. 50).
Allows you to configure functions on a single screen (p. 124).
Cancels the setting and returns to the previ-
ous screen.
Sets the measurement speed (p. 73).
Configures averaging (p. 74).
Sets the trigger delay (p. 76).
Configures the trigger synchronous output
function (p. 77).
