8.3 Compensating Values to Match Reference Values (Load Compensation)
242
and Reference Value Settings
If you make a mistake during input:
press to cancel the input and start again.
2. Use the numeric keypad to enter the reference value.
Reference Value Setting
Load Compensation Setting
1. Press (reference value1).
3. Press a instrument key to confirm the setting.
4. Press to confirm the setting.
5. Also set (reference value2) in the same way.
• If the compensation frequency, compensation range, and compensation signal level are
not set, the reference value setting cannot be set.
• When DC is selected for the compensation frequency setting, only reference value 1 can be
set.
