10.3 Self Checks (Self Diagnosis)
270
Check the internal memory (ROM and RAM) of the instrument.
ROM/RAM Test
You can check the internal memory in mode, mode, or mode.
LCR Measurement Screen
1
Self Checks
Procedure
Press .
2
Self Checks
• Press the button
to start the test automatically. (Approx. 40 seconds)
• No operation is possible during the ROM/RAM test.
Never turn off the power during a test.
3
ROM/RAM Test (When IM3533)
If the overall judgment result indication is [PASS],
the test ended normally.
If the overall judgment result indication is [NG], the in-
strument needs to be repaired.Contact your authorized
Hioki distributor or reseller.
ROM/RAM Test (When IM3533-01)
Overall judgment result
4
Press to close the setting screen.
