Hioki IM3533 - Page 292

11.4 Saving Measurement Data
284
Press .
6
7
Press in the measurement screen.
The measurement data is saved.
USB Flash Drive Recognition
When is pressed, a folder is automatically
created in the USB flash drive and the file is saved.
• The date is used for the name of the folder cre-
ated when you press .
• The date and time are automatically assigned to
the file name.
See "Changing the Save Folder" (p. 291)
When performing measurement in ANALYZER mode, do not save measurement data
partway through the series of frequency points.
