Priority Order
Measurement Error Screen Indication
Measurement Status
Measurement Values
(Upper Portion: When text save,
the memory function (short Format),
Lower Portion: When the memory function
(Long Format))
When saved by the memory
function
Comparator
Measurement
BIN
Measure-
ment
Logical
Product
Each
Parameter
Judgment
Result
BIN
No
Sampling error 9
999999E+28
01
*1
-1
9999999999E+28
Overcurrent error 19
999999E+28
01
*1
-1
9999999999E+28
H side and L side
contact error
(AFTER)
17
999999E+28
01
*1
-1
9999999999E+28
L side contact error
(AFTER)
16
999999E+28
01
*1
-1
9999999999E+28
H side contact error
(AFTER)
15
999999E+28
01
*1
-1
9999999999E+28
H side and L side
contact error
(BEFORE)
14
999999E+28
01
*1
-1
9999999999E+28
L side contact error
(BEFORE)
13
999999E+28
01
*1
-1
9999999999E+28
H side contact error
(BEFORE)
12
999999E+28
01
*1
-1
9999999999E+28
Underflow -7
-999999E+28
0-1
*1, 2
-1
-9999999999E+28
Overflow 7
999999E+28
01
*1, 3
-1
9999999999E+28
Outside of HIGH-Z
reject limit range
5
Normal Measurement Values
Normal
judgment
Normal
judgment
Normal
judgment
Normal Measurement Values
Outside of display
range
*4
3
Normal Measurement Values
Normal
judgment
Normal
judgment
Normal
judgment
Normal Measurement Values
Temperature correc-
tion sensor error
(temperature correction)
18
Normal Measurement Values
Normal
judgment
1
Normal
judgment
Normal Measurement Values
Outside of guaran-
teed accuracy range
2
Normal Measurement Values
Normal
judgment
Normal
judgment
Normal
judgment
Normal Measurement Values
Normal
Measurement
Values
0
Normal Measurement Values
Normal
judgment
Normal
judgment
Normal
judgment
Normal Measurement Values
No measurement af-
ter power turned on
1
999999E+28
02-2
9999999999E+28
*1 The judgment result will be 2 when comparator judgment is not mode.
*2 The judgment result will be 1 when the parameters are Y, Cs, Cp, G, and B.
*3 The judgment result will be -1 when the parameters are Y, Cs, Cp, G, and B.
*4 For the outside of the display range to which a temperature sensor is not connected, “999999E+28” is returned as a short form and
“9999999999E+28” is returned as a long form.
