11.4 Saving Measurement Data
286
When TRANSFORMER mode
Priority Order
Measurement Error Screen Indication
Measurement Status
Measurement Values
(Upper Portion: When text save,
the memory function (short Format),
Lower Portion: When the memory function
(Long Format))
When saved by the
memory function
Comparator Measurement
Outside of display
range*1
3
999999E+28
1/2
*2
9999999999E+28
Outside of HIGH-Z
reject limit range
5
Normal Measurement Values
Normal judgment
Normal Measurement Values
Outside of guaran-
teed accuracy range
2
Normal Measurement Values
Normal judgment
Normal Measurement Values
Normal
Measurement
Values
0
Normal Measurement Values
Normal judgment
Normal Measurement Values
No measurement af-
ter power turned on
1
999999E+28
2
9999999999E+28
*1 When L1, L2 cannot be measured correctly.
*2 Returns 2 if either L1 or l2 has not been measured, or 1 if a measurement parameter is erroneous or calculation is impossible.
Lo
High
The measurement status indicates the error response saved with the memory function by
the
:MEASure:VALIid setting.
For more information about how to set
:MEASure:VALid, see the Communications
Command Instruction Manual (LCR Application Disk).
