12.1 External Input/Output Connector and Signals
311
12
Chapter 12 External Control
LCR mode
Pin I/O Signal name Function Logic
1INTRIG External trigger (p. 316)
Pos/
Neg
Edge
2 - (Unused) -
--
3 - (Unused) -
--
4INLD1 Select panel number (p. 316)
Neg Level
5INLD3 Select panel number (p. 316)
Neg Level
6INLD5 Select panel number (p. 316)
Neg Level
7 - (Unused) -
--
8 - ISO_5V Isolated 5 V power output
--
9 - ISO_COM Isolated common signal ground
--
10 OUT ERR
Outputs when a sampling error, overcurrent error, contact error,
HIGH-Z reject error, temperature sensor error, constant voltage/
constant current error, or voltage/current limit value exceeded
error occurs.
Neg Level
11 OUT BIN1, PARA1-HI
Outputs BIN measurement results and HI comparator judgment
results for the No. 1 parameter.
Neg Level
12 OUT BIN3, PARA1-LO
Outputs BIN measurement results and LO comparator judgment
results for the No. 1 parameter.
Neg Level
13 OUT BIN5, PARA3-IN
Outputs BIN measurement results and IN comparator judgment
results for the No. 3 parameter.
Neg Level
14 OUT BIN7
AND
BIN judgment results
Outputs results obtained by applying an AND operation to the
judgment results for measurement results for two parameters.
When both judgment results are IN or one of the No. 1 or No. 3
parameters has not been judged, outputs when the judgment re-
sult for the parameter that has been judged is IN.
Neg Level
15 OUT BIN9
BIN judgment results
Neg Level
16 - (Unused) -
--
17 - (Unused) -
--
18 - (Unused) -
--
19 OUT OUT_OF_BINS
BIN judgment results
Neg Level
20 - (Unused) -
--
21 - (Unused) -
--
22 IN LD0 Select panel number (p. 316)
Neg Level
23 IN LD2 Select panel number (p. 316)
Neg Level
24 IN LD4 Select panel number (p. 316)
Neg Level
25 IN LD6 Select panel number (p. 316)
Neg Level
26 IN LD_VALID Execute panel load (p. 316)
Neg Level
27 - ISO_COM
Isolated common signal ground
--
28 OUT EOM
Measurement complete signal: When this signal is output, the
comparator judgment results have been finalized.
Neg Edge
29 OUT INDEX
Signal indicating that A/D conversion for the measurement cir-
cuit has completed: When this signal changes from high (off) to
low (on), the sample may be changed.
Neg Edge
30 OUT BIN2, PARA1-IN
BIN judgment results.
Outputs IN comparator judgment results for the No. 1 parameter.
Neg Level
31 OUT BIN4, PARA3-HI
BIN judgment results.
Outputs HI comparator judgment results for the No. 3 parameter.
Neg Level
