12.1 External Input/Output Connector and Signals
312
32 OUT BIN6, PARA3-LO
BIN judgment results.
Outputs LO comparator judgment results for the No. 3 parameter.
Neg
Level
33 OUT BIN8
BIN judgment results
Neg
Level
34 OUT BIN10
BIN judgment results
Neg
Level
35 - (Unused) -
--
36 - (Unused) -
--
37 - (Unused) -
--
Pin I/O Signal name Function Logic
ANALYZER mode (IM3533-01 only)
Pin I/O Signal name Function Logic
1INTRIG External trigger (p. 316)
Pos/
Neg
Edge
2 - (Unused) -
--
3 - (Unused) -
--
4INLD1 Select panel number (p. 316)
Neg
Level
5INLD3 Select panel number (p. 316)
Neg
Level
6INLD5 Select panel number (p. 316)
Neg
Level
7 - (Unused) -
--
8 - ISO_5V Isolated 5 V power output
--
9 - ISO_COM Isolated common signal ground
--
10 OUT ERR
Outputs when a sampling error, overcurrent error, contact error,
HIGH-Z reject error, or constant voltage/constant current error oc-
curs.
Neg
Level
11 - (Unused)
-
--
12 - (Unused)
-
--
13 - (Unused) -
--
14 - (Unused)
-
--
15 - (Unused) -
--
16 - (Unused) -
--
17 - (Unused) -
--
18 - (Unused) -
--
19 - (Unused) -
--
20 - (Unused) -
--
21 - (Unused) -
--
22 IN LD0
Select panel number (p. 316)
Neg
Level
23 IN LD2
Select panel number (p. 316)
Neg
Level
24 IN LD4
Select panel number (p. 316)
Neg
Level
25 IN LD6
Select panel number (p. 316)
Neg
Level
26 IN LD_VALID
Execute panel load (p. 316)
Neg
Level
27 - ISO_COM
Isolated common signal ground
--
28 OUT EOM
Measurement complete signal: When this signal is output, the
comparator judgment results have been finalized.
Neg
Edge
To Next Page
