12.1 External Input/Output Connector and Signals
313
12
Chapter 12 External Control
29 OUT INDEX
Signal indicating that A/D conversion for the measurement cir-
cuit has completed: When this signal changes from high (off) to
low (on), the sample may be changed.
Neg
Edge
30 - (Unused)
-
--
31 - (Unused) -
--
32 - (Unused) -
--
33 - (Unused) -
--
34 - (Unused) -
--
35 - (Unused) -
--
36 - (Unused) -
--
37 - (Unused) -
--
Pin I/O Signal name Function Logic
Pin I/O Signal name Function Logic
1INTRIG External trigger (p. 316)
Pos/
Neg
Edge
2 - (Unused) -
--
3 - (Unused) -
--
4INLD1
(p. 316)
Select panel number (p. 316)
Neg
Level
5INLD3 Select panel number (p. 316)
Neg
Level
6INLD5 Select panel number (p. 316)
Neg
Level
7 - (Unused) -
--
8 - ISO_5V Isolated 5 V power output
--
9 - ISO_COM Isolated common signal ground
--
10 OUT ERR
Outputs when a sampling error, contact error, HIGH-Z reject er-
ror, constant voltage/constant current error, or voltage/current
limit value exceeded error occurs.
Neg
Level
11 OUT HI
Outputs HI comparator judgment results.
Neg
Level
12 OUT LO
Outputs LO comparator judgment results.
Neg
Level
13 - (Unused) -
--
14 OUT AND
Returns the result of an AND operation. Outputs only when the
judgment results in TRANSFORMER mode are IN.
Neg
Level
15 - (Unused) -
--
16 - (Unused) -
--
17 - (Unused) -
--
18 - (Unused) -
--
19 - (Unused) -
--
20 - (Unused) -
--
21 - (Unused) -
--
22 IN LD0
specification (p. 316)
Select panel number (p. 316)
Neg
Level
23 IN LD2
Select panel number (p. 316)
Neg
Level
24 IN LD4
Select panel number (p. 316)
Neg
Level
25 IN LD6
Select panel number (p. 316)
Neg
Level
To Next Page
