12.1 External Input/Output Connector and Signals
314
26 IN LD_VALID
Execute panel load (p. 316)
Neg
Level
27 - ISO_COM
Isolated common signal ground
--
28 OUT EOM
Measurement complete signal: When this signal is output, the
comparator judgment results have been finalized.
Neg
Edge
29 OUT INDEX
Signal indicating that A/D conversion for the measurement cir-
cuit has completed: When this signal changes from high (off) to
low (on), the sample may be changed.
Neg
Edge
30 OUT IN
Outputs IN comparator judgment results.
Neg
Level
31 - (Unused) -
--
32 - (Unused) -
--
33 - (Unused) -
--
34 - (Unused) -
--
35 - (Unused) -
--
36 - (Unused) -
--
37 - (Unused) -
--
Pin I/O Signal name Function Logic
1INTRIG External trigger (p. 316)
Pos/
Neg
Edge
2 - (Unused) -
--
3 - (Unused) -
--
4 - (Unused) -
--
5 - (Unused) -
--
6 - (Unused) -
--
7 - (Unused) -
--
8 - ISO_5V Isolated 5 V power output
--
9 - ISO_COM Isolated common signal ground
--
10 OUT ERR
Outputs when a sampling error, overcurrent error, contact error,
HIGH-Z reject error, temperature sensor error, constant voltage/
constant current error, or voltage/current limit value exceeded
error occurs.
Neg
Level
11 OUT No.1_PARA1-HI
Outputs HI comparator judgment results for the first No. 1 pa-
rameter.
Neg
Level
12 OUT No.1_PARA1-LO
Outputs LO comparator judgment results for the first No. 1 pa-
rameter.
Neg
Level
13 OUT No.1_PARA3-IN
Outputs IN comparator judgment results for the first No. 3 pa-
rameter.
Neg
Level
14 OUT AND
Outputs when all panel judgments are IN and the instrument is
not OUT_OF_BINS.
Neg
Level
15 OUT No.2_PARA1-IN
Outputs IN comparator judgment results for the second No. 1
parameter.
Neg
Level
16 OUT No.2_PARA3-HI
Outputs HI comparator judgment results for the second No. 3
parameter.
Neg
Level
17 OUT No.2_PARA3-LO
Outputs LO comparator judgment results for the second No. 3
parameter.
Neg
Level
18 - (Unused) -
--
19 - (Unused) -
--
Pin I/O Signal name Function Logic
CONTINUOUS measurement mode
