12.1 External Input/Output Connector and Signals
315
12
Chapter 12 External Control
20 - (Unused) -
--
21 - (Unused) -
--
22 - (Unused) -
--
23 - (Unused) -
--
24 - (Unused) -
--
25 - (Unused) -
--
26 - (Unused) -
--
27 - ISO_COM
Isolated common signal ground
--
28 OUT EOM
Measurement complete signal: When this signal is output, the
comparator judgment results have been finalized.
Neg
Edge
29 OUT INDEX
Signal indicating that A/D conversion for the measurement cir-
cuit has completed: When this signal changes from high (off) to
low (on), the sample may be changed.
Neg
Edge
30 OUT No.1_PARA1-IN
Outputs IN comparator judgment results for the first No. 1 pa-
rameter.
Neg
Level
31 OUT No.1_PARA3-HI
Outputs HI comparator judgment results for the first No. 3 pa-
rameter.
Neg
Level
32 OUT No.1_PARA3-LO
Outputs LO comparator judgment results for the first No. 3 pa-
rameter.
Neg
Level
33 OUT No.2_PARA1-HI
Outputs HI comparator judgment results for the second No. 1
parameter.
Neg
Level
34 OUT No.2_PARA1-LO
Outputs LO comparator judgment results for the second No. 1
parameter.
Neg
Level
35 OUT No.2_PARA3-IN
Outputs IN comparator judgment results for the second No. 3
parameter.
Neg
Level
36 - (Unused) -
--
37 - (Unused) -
--
Pin I/O Signal name Function Logic
