14.2 Measurement Range and Accuracy
345
14
Chapter 14 Specifications
E Cable length coefficient
The coefficient corresponding to the setting for measurement cable length is obtained from the measurement
cable length table and then multiplied by the basic accuracy.
* IM3533 guaranteed accuracy range (frequency)
* IM3533-01 guaranteed accuracy range (frequency)
0 m / 1 m / 2 m / 4 m: Up to 200 kHz (no limit)
F DC bias coefficient
The coefficient corresponding to the setting for ON/OFF of DC bias is obtained from the DC bias coefficient
table and then multiplied by the basic accuracy.
G Temperature coefficient
The coefficient corresponding to the operating temperature is obtained from the operating temperature coeffi-
cient table and then added to the basic accuracy.
0 m 1 m 2 m 4 m
Cable length
coefficient
IM3533
10 k
 range or less 1 1.2
100 k range or greater 1 1.2
IM3533-01 1 1.2 1.5 2
fm: Measurement frequency [kHz]
1.5
fm
100
----------+
2
fm
50
-------+
1.5
fm
20
-------+
2
fm
10
-------+
Cable length 10 k range or less 100 k range or greater
Guaranteed accuracy range
(frequency)
0 m
Up to 200 kHz
1 m
Up to 200 kHz
2 m
Up to 200 kHz Up to 100 kHz
4 m
Up to 200 kHz Up to 10 kHz
DC Bias Setting OFF DC Bias Setting ON
DC bias
coefficient
12
0°C  t < 18°C, 28°C < t  40°C 18°C  t  28°C
Temperature
coefficient
1+0.1
× |t - 23| 1
When the operating temperature (t) is 23C ±5C, the coefficient is 1.
