Contents
iii
Appendix
Index
5.3.9 Disabling Key Operation
(Key-lock Function) ..........................186
5.3.10Enabling Trigger Input for during Mea-
surement and Setting the Valid Edge of
Trigger Input .....................................189
5.3.11Setting the EOM
Output Method .....190
5.3.12Initializing (System Reset) ...............191
Chapter 6 TRANSFORMER
Function 193
6.1 About TRANSFORMER function .....193
6.1.1 Measurement screen .......................193
6.1.2 Measurement Methods ....................194
6.1.3 Setting the measurement parameter 196
6.1.4 Setting Calculation Parameters .......197
6.2 Setting Basic Settings of Measurement
Conditions ........................................198
6.3 Judging with Upper and Lower Limit
Values (Comparator Measurement
Mode) ...............................................199
 Setting the Upper or Lower Limit Value as
an Absolute Value (ABS)
(Absolute Value Mode) ...........................202
 Setting the Upper or Lower Limit Value as
a Percentage (%) Relative to a Reference
Value (Percentage Mode) .......................203
 Setting Upper and Lower Limit Values as
(%) Values Relative to the Offset from the
Reference Value
(Deviation Percentage Mode) .................205
6.4 Setting Application Settings .............207
Chapter 7 CONTINUOUS
Measurement
Function 209
7.1 About CONTINUOUS Measurement
Function ...........................................209
7.1.1 Measurement screen .......................209
7.2 Configuring CONTINUOUS
Measurement Basic Settings ...........210
7.3 Performing CONTINUOUS
Measurement ...................................211
7.4 Checking CONTINUOUS Measurement
Results .............................................212
7.5 Configuring CONTINUOUS
Measurement Application Settings .. 213
7.5.1 Setting the Display Timing ............... 213
7.5.2 Setting the LCD to ON/OFF ............. 214
Chapter 8 Error
Compensation 215
8.1 Setting Open Circuit Compensation 215
8.1.1 All Compensation ............................ 216
8.1.2 Spot Compensation ......................... 220
8.2 Short Circuit Compensation ............. 224
8.2.1 All Compensation ............................ 226
8.2.2 Spot Compensation ......................... 228
8.3 Compensating Values to Match
Reference Values
(Load Compensation) ...................... 232
8.4 Compensating Measurement Cable
Errors (Cable Length Compensation)
......................................................... 245
8.5 Calculating Values (Scaling) ............ 246
Chapter 9 Saving and Loading
Panel Information
249
9.1 Saving Measurement Conditions
(Panel Save Function) ..................... 251
9.2 Loading Measurement Conditions
(Panel Load Function) ..................... 256
9.3 Changing a Panel Name ................. 258
9.4 Deleting a Panel .............................. 260
Chapter 10 Setting the
SYSTEM 263
10.1 Setting the Interface ........................ 263
10.2 Checking the Version of the
Instrument ....................................... 264
10.3 Self Checks (Self Diagnosis) ........... 265
10.4 Setting the Date and Time ............... 272
1
2
3
4
5
6
7
8
9
10
11
12
14
13
