Contents
iv
Chapter 11 Using USB Flash
Drive 273
11.1 Inserting and Removing USB flash
drive ..................................................274
11.2 About the File Operation Screen ......275
11.3 About the File Save Setting Screen .276
11.4 Saving Measurement Data ...............277
 Saving Measurement Data .................... 277
 Saving a Copy of the Screen ................. 287
 Checking the Contents of Files .............. 290
 Changing the Save Folder ..................... 291
11.5 Saving Instrument Settings ..............293
 Saving Instrument Settings .................... 293
 Saving All Settings of Instrument
(ALL SAVE Function) ............................. 295
11.6 Loading Instrument Settings .............297
 Loading instrument settings ................... 297
 Loading all settings saved on a USB flash
drive ....................................................... 300
 (ALL LOAD Function) ............................. 300
11.7 File and Folder Operations ...............302
 Formatting a USB Flash Drive ............... 302
 Deleting Files and Folders ..................... 304
 Creating Folders .................................... 305
 Displaying the USB Flash Drive
Information ............................................. 307
Chapter 12 External Control309
12.1 External Input/Output Connector and
Signals 309
 Connector Type and Signal Pinouts ...... 310
 Signal function details ............................ 316
12.2 Timing Chart .....................................318
12.2.1LCR Mode .......................................318
12.2.2ANALYZER Mode (IM3533-01 only) 321
12.2.3TRANSFORMER Mode ...................322
12.2.4CONTINUOUS Measurement Mode 323
12.3 Internal Circuitry ...............................325
 Electrical Specifications ......................... 326
 Connection Examples ............................ 327
12.4 External I/O Settings ........................328
 Setting Delay Time from Output of Compara-
tor and BIN Judgment Results until Output
of EOM
(LOW) ....................................... 328
 Setting Reset of Judgment Results ........ 328
 Enabling Trigger Input for during
Measurement ......................................... 328
 Setting Valid Edge of Trigger Input ........ 328
12.5 External Control Q&A ...................... 329
12.6 Measurement Using a Computer ..... 329
Chapter 13Printing 331
13.1 Connecting the Printer ..................... 331
 Connecting the Printer to the Instrument 332
13.2 Instrument and Printer Settings ....... 333
 Make Instrument Settings ...................... 333
13.3 Printing ............................................. 334
Chapter 14Specifications 337
14.1 General Specifications ..................... 337
14.2 Measurement Range and Accuracy 342
14.3 About Measurement Times and
Measurement Speed ....................... 350
Chapter 15Maintenance and
Service 353
15.1 Inspection, Repair and Cleaning ...... 353
15.2 Troubleshooting ............................... 355
15.3 Error display ..................................... 360
15.4 Discarding the Instrument ................ 362
Appendix A 1
Appendix1 Measurement Parameters and
Calculation Formula .................A 1
Appendix2 Measurement of High Impedance
Components.............................A 3
Appendix3 Measurement of In-circuit Compo-
nents.........................................A 4
Appendix4 Countermeasures Against Incorpo-
ration of External Noise............A 5
Appendix4.1Countermeasures Against Incor-
poration of Noise from the Power
Line ..........................................A 5
