4.2 Setting Basic Settings of Measurement Conditions
63
4
Chapter 4 LCR Function
Setting AUTO Ranging
LCR Measurement Screen
1
LCR Basic Settings
Procedure
Press .
2
LCR Basic Settings
Press .
3
• The ranges that can be set vary with the fre-
quency. (p. 67)
• When you want to control the AUTO ranging
range:
See "AUTO range limit function" (p. 64)
• If the instrument is being used outside the limits of
its specification, the suitable range may not be set
in auto ranging function. In this case, check the
accuracy assured ranges in "14.2 Measurement
Range and Accuracy" (p. 342) and then change
the test conditions.
Range Setting
4
Press to close the setting screen.
