4.3 Setting DC Resistance Measurement
91
4
Chapter 4 LCR Function
Select the AUTO range lower limit range.
5
AUTO Range Limit Range Setting
6
Touch to accept the lower limit range.
7
Return to step 4, touch , and select the AUTO range upper limit range.
When canceling the AUTO range limit function, set the lower limit range to 100 m and the
upper limit range to 100 M.
8
Press to close the setting screen.
Screen displayed when the AUTO range limit function has been enabled
Example: When the upper limit range is set to 1 k and the lower limit range is set to 1 M
Operation is only enabled within the set AUTO ranging
range.
