Quidway S3900 Series Ethernet Switches Chapter 1 Mirroring Configuration
Huawei Technologies Proprietary
1-12
III. Configuring RSPAN on the intermediate switch
Table 1-10 Configure RSPAN on the intermediate switch
Operation Command Description
Enter system view
system-view
—
Create a remote-probe
VLAN and enter VLAN
view
vlan vlan-id
vlan-id is the ID of the
remote-probe VLAN.
Define the current
VLAN as a
remote-probe VLAN
remote-probe vlan enable
Required
Exit current view
quit
—
Enter Ethernet port
view of Trunk port
through which the
intermediate switch is
connected to the
source switch,
destination switch or
another intermediate
switch
interface interface-type
interface-number
—
Configure Trunk port to
permit packets from
the remote-probe
VLAN
port trunk permit vlan
remote-probe-vlan-id
Required
This configuration is
necessary for ports on
the intermediate switch
that are connected to
the source switch or
the destination switch.
IV. Configuring RSPAN on the destination switch
Table 1-11 Configure RSPAN on the destination switch
Operation Command Description
Enter system view
system-view
—
Create a remote-probe
VLAN and enter VLAN
view
vlan vlan-id
vlan-id is the ID of the
remote-probe VLAN.
Define the current
VLAN as a
remote-probe VLAN
remote-probe vlan enable
Required
Exit the current view
quit
—
