Quidway S3900 Series Ethernet Switches Chapter 1 Mirroring Configuration
Huawei Technologies Proprietary
1-16
[Quidway-vlan10] quit
[Quidway] interface GigabitEthernet 1/1/1
[Quidway-GigabitEthernet1/1/1] port trunk permit vlan 10
[Quidway-GigabitEthernet1/1/1] quit
[Quidway] interface GigabitEthernet 1/1/2
[Quidway-GigabitEthernet1/1/2] port trunk permit vlan 10
# Configure Switch A.
<Quidway> system-view
[Quidway] vlan 10
[Quidway-vlan10] remote-probe vlan enable
[Quidway-vlan10] quit
[Quidway] interface gigabitethernet1/0GigabitEthernet 1/1/1
[Quidway-GigabitEthernet1/01/1] port trunk permit vlan 10
[Quidway-GigabitEthernet1/01/1] quit
[Quidway] mirroring-group 1 remote-destination
[Quidway] mirroring-group 1 monitor-port gigabitethernet1/0GigabitEthernet
1/1/2
[Quidway] mirroring-group 1 remote-probe vlan 10
[Quidway] display mirroring-group remote-destination
mirroring-group 1:
type: remote-destination
status: active
monitor port: GigabitEthernet1/01/2
remote-probe vlan: 10
1.3.4 Displaying Mirroring
After the above configuration, you can use the display command in any view to view
the mirroring running information, so as to verify the configurations you made.
Table 1-12 Display mirroring
Operation Command
Display parameter settings of
a mirroring group
display mirroring-group { group-id | all | local |
remote-destination | remote-source }
Display parameter settings of
traffic mirroring
display qos-interface { interface-type
interface-number | unit-id } mirrored-to
