Husqvarna TE511 - Page 296

M.16
H06283
19
18
16
H06282
H06445
17
H06293
15
ELECTRICAL SYSTEM
1
st
edition (08-2010)_Rev. 11-2010
- Electric fan (15);
- A 10A (lights) fuse (16) positioned below the headlamp fairing and a 30A
(main) fuse (17) positioned on the solenoid starter;
- Coolant temperature sensor (18);
- Lambda sensor (19);
