Husqvarna TE511 - Page 360

X.4 1
st
edition (08-2010) _Rev. 11-2010
TIGHTENING TORQUE FIGURES
Assembly Cycle Operation Description Nm Kgm ft/lb
LEFT SWITCH FASTENING 2,50 0,25 1,84
CLUTCH MASTER CYLINDER FASTENING 5,00 0,50 3,69
HANDLEBAR CLAMPS FASTENING 45,00 4,50 33,19
INSTRUMENT PANEL PLATE FASTENING 5,00 0,50 3,69
FUEL PUMP FASTENING 7,00 0,70 5,16
COCK FASTENING 1,50 0,15 1,11
COCK FASTENING ("US" TANK) 9,00 0,90 6,64
SOLENOID STARTER MOUNT.PLATE FASTENING 4,00 0,40 2,95
COCK FASTENING 1,50 0,15 1,11
COCK FASTENING ("US" TANK) 9,00 0,90 6,64
TANK FASTENING 2,00 0,20 1,48
REAR CHASSIS TO TANK PAD FASTENING 8,00 0,80 5,90
RIGHT REAR CHASSIS TO SIDE PANEL PAD FASTENING 8,00 0,80 5,90
LEFT REAR CHASSIS TO SIDE PANEL PAD FASTENING 8,00 0,80 5,90
NUMBER PLATE LIGHT FASTENING 3,00 0,30 2,21
SADDLE SPACER FASTENING 10,00 1,00 7,38
SIDE PANELS TO REAR MUDGUARD FASTENING 8,00 0,80 5,90
NUMBER PLATE HOLDER FASTENING 8,00 0,80 5,90
SIDE PANELS TO REAR CHASSIS FASTENING 5,00 0,50 3,69
SIDE PANELS TO REAR MUDGUARD COUPLING 1,00 0,10 0,74
1 Nm = 0.73756 ft/lb
