Assembly Cycle Operation Description Nm Kgm ft/lb
SILENCER TO REAR CHASSIS FASTENING 25,00 2,50 18,44
MANIFOLD FLANGE NUT FASTENING 13,00 1,30 9,59
SILENCER CLAMP FASTENING 20,00 2,00 14,75
HEADLIGHT TO GRILLE FASTENING 10,00 1,00 7,38
RING TO GRILLE/NUMBER HOLDER FASTENING 0,70 0,07 0,52
PUSHROD TO MUDGUARD TAIL FASTENING 1,00 0,10 0,74
NUMBER HOLDER/GRILLE TO MUDGUARD FASTENING 1,00 0,10 0,74
MUDGUARD TO BOTTOM YOKE FASTENING 10,00 1,00 7,38
FORK LEG PROTECTION FASTENING 10,00 1,00 7,38
CABLE GUIDE PLATE TO LEFT FORK LEG PROTECTION FASTENING 1,20 0,12 0,89
TAILLIGHT TO NUMBER PLATE HOLDER FASTENING 1,50 0,15 1,11
SIDE STAND PIN FASTENING (WITH LOCTITE 243) 12,00 1,20 8,85
CHASSIS PROTECTION TO SWINGING ARM PIN FASTENING 5,00 0,50 3,69
REAR BRAKE LEVER FASTENING (WITH LOCTITE 243) 42,00 4,20 30,98
FRONT WHEEL AXLE FASTENING 52,00 5,20 38,35
FRONT BRAKE CALLIPER TO LEFT FORK LEG FASTENING 28,00 2,80 20,65
REAR SHOCK ABSORBER PROTECTION FASTENING 5,00 0,50 3,69
CLUTCH ACTUATOR COVER TO ENGINE FASTENING 5,00 0,50 3,69
REAR WHEEL AXLE FASTENING 142,00 14,20 104,73
CHASSIS PROTECTION TO CHAIN ROLLER FASTENING 10,00 1,00 7,38
HORN FASTENING 5,00 0,50 3,69
RIGHT SCOOP FASTENING 5,00 0,50 3,69
LEFT SCOOP FASTENING 5,00 0,50 3,69
LEFT SIDE PANEL FASTENING 5,00 0,50 3,69
RIGHT SIDE PANEL FASTENING 5,00 0,50 3,69
ENGINE PROTECTION TO CHASSIS FASTENING 10,00 1,00 7,38
NUMBER HOLDER/FRONT FAIRING TO INSTRUMENT PLATE FASTENING 10,00 1,00 7,38
SWINGING ARM PIN BUSHES TO SWINGING ARM FASTENING 3,00 0,30 2,21
DROP LINK TO SWINGING ARM FASTENING 80,00 8,00 59,00
DROP LINK TO DRAG LINK FASTENING 50,00 5,00 36,88
BRAKE HOSE GROMMET TO SWINGING ARM FASTENING 4,00 0,40 2,95
CHAIN SLIDER TO SWINGING ARM FASTENING 4,00 0,40 2,95
CHAIN COVER AND SLIDER TO SWINGING ARM FASTENING 4,00 0,40 2,95
NUT FOR CHAIN TENSIONER ADJUSTER FASTENING 22,00 2,20 16,23
CHAIN GUIDE TO SWINGING ARM FASTENING 11,00 1,10 8,11
BRAKE HOSES TO CYLINDERS/CALLIPERS FASTENING 19,00 1,90 14,01
BRAKE FLUID BLEEDER VALVE FASTENING 14,00 1,40 10,33
FRONT BRAKE MASTER CYLINDER FASTENING 5,00 0,50 3,69
THROTTLE CONTROL FASTENING 3,00 0,30 2,21
