Assembly Cycle Operation Description Nm Kgm ft/lb
BRAKE PEDAL ADJUSTING CAMS TO CHASSIS FASTENING 10,00 1,00 7,38
CHASSIS CHAIN SLIDER TO TRANSVERSAL LOWER TUBE FASTENING 1,00 0,10 0,74
CONDENSER PLATE TO ENGINE FASTENING 10,00 1,00 7,38
ENGINE FRONT PLATE TO ENGINE FASTENING (WITH LOCTITE 270) 25,00 2,50 18,44
ENGINE PROT. PLATE FASTENING 25,00 2,50 18,44
STEERING LOCK TO CHASSIS FASTENING 22,00 2,20 16,23
STEERING STEM RING NUT FASTENING 4,00 0,40 2,95
STEERING HEAD NUT FASTENING 82,00 8,20 60,48
STEERING PLATE BOTTOM SCREW FASTENING 21,00 2,10 15,49
STEERING PLATE TOP SCREW FASTENING 19,00 1,90 14,01
HANDLEBAR TOP CLAMP FASTENING 28,00 2,80 20,65
SWINGING ARM PIN FASTENING 100,00 10,00 73,76
CHASSIS-SIDE DRAG LINK FASTENING 80,00 8,00 59,00
CHAIN GUIDE PLATE FASTENING 10,00 1,00 7,38
ENGINE LOWER FASTENING 50,00 5,00 36,88
THROTTLE BODY CLAMP FASTENING 0,30 0,03 0,22
THROTTLE BODY COVER FASTENING 3,00 0,30 2,21
SHOCK ABSORBER TO DROP LINK FASTENING 50,00 5,00 36,88
SHOCK ABSORBER TO CHASSIS FASTENING 50,00 5,00 36,88
REAR BRAKE MASTER CYLINDER FASTENING 10,00 1,00 7,38
STARTER MOTOR FASTENING 10,00 1,00 7,38
POSITIVE CABLE TO STARTER MOTOR FASTENING 8,00 0,80 5,90
FILTER BOX BASE FASTENING 8,00 0,80 5,90
INTAKE FUNNEL TO THROTTLE BODY FASTENING 0,70 0,07 0,52
REAR CHASSIS FASTENING 25,00 2,50 18,44
GROUND CABLE TO ENGINE HEAD FASTENING 5,00 0,50 3,69
CONNECTING ROD TO CHASSIS FASTENING 42,00 4,20 30,98
FUEL TANK TO ENGINE FASTENING 10,00 1,00 7,38
ENGINE CENTRAL FASTENING 50,00 5,00 36,88
WATER TEMPERATURE SENSOR FASTENING 10,00 1,00 7,38
FOR ELECTRIC FAN PLATES FASTENING 5,00 0,50 3,69
ELECTRIC FAN FASTENING 3,00 0,30 2,21
VOLTAGE REGULATOR FASTENING 10,00 1,00 7,38
COOLING SYSTEM PIPE FASTENING 1,50 0,15 1,11
RADIATOR TO CHASSIS FASTENING 10,00 1,00 7,38
CLUTCH ACTUATOR TO ENGINE FASTENING 10,00 1,00 7,38
LAMBDA SENSOR FASTENING 25,00 2,50 18,44
SILENCER PIPE TO CHASSIS FASTENING 20,00 2,00 14,75
