Husqvarna TE511 - Page 72

E.14
H02439
14
H02440
16
15
H02441
1
st
edition (08-2010) _Rev. 11-2010
GENERAL PROCEDURES
TC;
- disconnect TPS connector (14).
- Loosen intake manifold (16) upper screw (15).
- Working on bike right side, slightly lift throttle body and turn it clockwise by
90°, then remove it from bike left side.
